Proximity Sensor ยี่ห้อ Omron
รุ่น E2E2-X10B1
(New)
|
Cylinder type sensing head size |
M30 |
|
Type |
Shielded |
|
Sensing method |
Inductive type |
|
Sensing distance |
10 mm -10% to +10% |
|
Setting distance |
0 to 8 mm |
|
Differential distance |
10% Max. of sensing distance |
|
Sensing object |
Ferrous metal (Sensitivity lowers with non-ferrous metals.) |
|
Standard sensing object |
Iron 30*30*1mm |
|
Response frequency |
400 Hz (average) |
|
Power supply voltage |
12 to 24 VDC (ripple(p-p) :10% Max.) |
|
Operating voltage range |
10 to 55 VDC |
|
Current consumption |
13 mA Max. |
|
Control output (Output type) |
PNP open collector output |
|
Control output (Switching capacity) |
0 to 200 mA (55VDC Max.) |
|
Control output (Residual voltage) |
2 V Max. （under load current with cable length of 2m） |
|
Indicator |
Operation indicator(red) |
|
Operation mode |
NO |
|
Protective circuit |
Surge suppressor
Output short-cut protection
Power supply reverse polarity protection |
|
Standard or Different frequency |
Standard |
|
Ambient temperature |
Operating: -40 to 85 CEL
Storage: -40 to 85 CEL
(with no icing or condensation) |
|
Ambient humidity |
Operating: 35 to 95 %RH
Storage: 35 to 95 %RH
(with no condensation) |
|
Temperature influence |
+-10% Max. of sensing distance in temperature range of -25 to +70CEL
+-15% Max. of sensing distance in temperature range of -40 to +85CEL
(As the basis for sensing distance of 23CEL) |
|
Voltage influence |
+-1% Max. of sensing distance in rated voltage range +-15%. (As the basis for sensing distance at standard power voltage) |
|
Insulation resistance |
50 M OHM Min. at 500VDC between charged parts and the case |
|
Dielectric strength |
1000 VAC 50/60 Hz for 1 minute between charged parts and the case |
|
Vibration resistance |
10 to 55 Hz, 1.5-mm double amplitude for 2 hours each in X, Y, and Z directions |
|
Shock resistance |
1000m/s2 for 10 times each in X, Y, and Z directions |
|
Degree of protection |
IEC60529: IP67 |
|
Applicable standard (EC Directive (Low Voltage Directive)) |
EN60947-1
EN60947-5-2 |
|
Applicable standard (EC Directive (EMC Directive)) |
EMI: EN60947-5-2
Emission Enclosure: CISPR11 Group 1 class A
EMS: EN60947-5-2
Immunity ESD: IEC61000-4-2
Immunity RF-interference: IEC61000-4-3
Immunity Burst: IEC61000-4-4
CE marking: Equipped |
|
Applicable standard (CCC mark) |
Not equipped |
|
Connection method |
M12 connector models |
|
Material (case) |
Brass nickel plating |
|
Material (sensing surface) |
PBT |
|
Material (clamping nuts) |
Brass nickel plating |
|
Material (toothed washer) |
Iron zinc plating |
|
Accessories |
Instruction manual |
